Features：
▸ SiN and TFLN heterogeneous integration technology
▸ Highly linear transmitter
▸ Integrated 8 optical lanes, each supports 106.25GBaud data transmission rate
▸ Compatible design for one LD input drivers 4 and 8 optical lanes, with total
on-chip loss (including 3dB working point) is 13.7dB and 16.7dB respectively
▸ Modulator 3dB EO bandwidth > 67GHz with Vpi < 3.0V
▸ Large spot size SSC design with I/O optical coupling loss is < 1.5dB, respectively
高速数通TFLN/SiN 异质集成Tx-PIC
Features：
▸SiN and TFLN heterogeneous integration technology
▸Highly linear transmitter
▸Integrated 8 optical lanes, each supports 106.25GBaud data transmission rate
▸One LD input drives two optical lanes
▸Integrated passive CWDM4 MUXs, with loss < 1dB and spectral
bandwidth > 13nm
▸Modulator 3dB EO bandwidth >67 GHz with Vpi < 3.0V
